RCJY55-XL-I INA

€ 66,15 ex VAT
€ 80,04 in VAT
€ 80,04 in VAT
€ 66,15 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

RCJY55-XL-I INA

Housing unit

Stock
24 pcs in stock and ready for shipment
Brand INA
Article number RCJY55-XL-I INA
Inside diameter 55mm
Outside diameter 162mm
Width 64,4mm
Product description

The RCJY55-XL-I INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJY55-XL-I INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 55
  2. Outer (D) MM 162
  3. Width (B) MM 64,4
  4. Inner (d) Inch 2.1654
  5. Outer (D) Inch 6.378
  6. Width (B) Inch 2.5354

Suffix description

  1. XL X-Life
  2. I Inch Size Grease Nipple R 1/8”

Technical details

  1. Availability 24 pcs
  2. Brand INA
  3. Item number RCJY55-XL-I INA
  4. Also known as 0009475980000
    NIP DIN71412-A R 1/8
    NIP DIN71412-B R 1/8
    NIP DIN71412-C R 1/8
    RCJY55-I
  5. EAN 4012802802870
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 3.41

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 29000
  2. Radial Dynamic Load Rating Cr (N) 46000
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Housing units RCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, R seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
Show all details Show less
