RCJY40-XL-N INA

Housing unit

Stock
91 pcs in stock and ready for shipment
Brand INA
Article number RCJY40-XL-N INA
Inside diameter 40,00mm
Outside diameter 130,00mm
Width 54,20mm
Product description

The RCJY40-XL-N INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJY40-XL-N INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 40,00
  2. Outer (D) MM 130,00
  3. Width (B) MM 54,20
  4. Inner (d) Inch 1.5748
  5. Outer (D) Inch 5.1181
  6. Width (B) Inch 2.1339
  7. Flange width (L) mm 130,00
  8. Total height unit (U) mm 54,20

Suffix description

  1. XL X-Life
  2. N Cast Iron Housing With Undercut Slot For End Caps

Technical details

  1. Availability 91 pcs
  2. Brand INA
  3. Item number RCJY40-XL-N INA
  4. Also known as 0008584200000
    RCJY40-N
  5. EAN 4012802797879
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.82

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 19800
  2. Radial Dynamic Load Rating Cr (N) 34500
  3. Basic static load rating, radial (C 0r) "19800.0000"
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Housing units RCJY, four-bolt flanged housing units, cast iron, grub screws in inner ring, R seals
