RCJY35-TV-VA-FD INA

€ 156,90 ex VAT
€ 189,85 in VAT
€ 189,85 in VAT
€ 156,90 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

RCJY35-TV-VA-FD INA

Housing and Bearing (assembly)

Stock
11 pcs in stock and ready for shipment
Brand INA
Article number RCJY35-TV-VA-FD INA
Inside diameter 35mm
Outside diameter 118mm
Width 46,4mm
Product description

The RCJY35-TV-VA-FD INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJY35-TV-VA-FD INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 35
  2. Outer (D) MM 118
  3. Width (B) MM 46,4
  4. Inner (d) Inch 1.378
  5. Outer (D) Inch 4.6457
  6. Width (B) Inch 1.8268
  7. Flange width (L) mm 117
  8. Total height unit (U) mm 46,9

Suffix description

  1. TV Plastic Housing
  2. VA Stainless Steel
  3. FD Food Compatible Grease-Fill

Technical details

  1. Availability 11 pcs
  2. Brand INA
  3. Item number RCJY35-TV-VA-FD INA
  4. Also known as 0971013970000
  5. EAN 4064327628855
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.73

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Food Grease
  3. Special Treatment Stainless Steel Bearing

Data from Schaeffler (medias)

  1. Basic static load rating, radial (C 0r) 12300
  2. Load carrying capacity (housing) (C 0r G) 18500

Downloads and links

  1. Link to manufacturer Link to manufacturer
Show all details Show less
