RCJY25-TV-VA-HLA INA

€ 117,58 ex VAT
€ 142,27 incl. VAT
€ 142,27 incl. VAT
€ 117,58 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CEST)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

RCJY25-TV-VA-HLA INA

Housing unit

Stock
47 pcs in stock and ready for shipment
Brand INA
Article number RCJY25-TV-VA-HLA INA
Inside diameter 25,00mm
Outside diameter 99,00mm
Width 36,80mm
Product description

The RCJY25-TV-VA-HLA INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJY25-TV-VA-HLA INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25,00
  2. Outer (D) MM 99,00
  3. Width (B) MM 36,80
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 3.8976
  6. Width (B) Inch 1.4488
  7. Flange width (L) mm 95,00
  8. Total height unit (U) mm 36,80

Suffix description

  1. TV Plastic Housing
  2. VA Stainless Steel
  3. HLA Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

  1. Availability 47 pcs
  2. Brand INA
  3. Item number RCJY25-TV-VA-HLA INA
  4. Also known as 0519584140000
    127557
    C4F25SS
    F4BC25M-TPSS
    F4B-SCEZ-25M-PCR
    FYWK25YTH
    MRC.C4F25SS
    MUC205 + FPL205SB
    MUCB205
    PSF25CR
    RCJY25TN VA
    RCJY25-TV-VA
    UC205S6 + VF205
    UCVF205S6
    YAR205-2RF/HV + FYWK505Y
  5. EAN 4054366718457
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.35

Product Properties

  1. Seal 2GU
  2. Lubrication Food Grease
  3. Special Treatment Stainless Steel Bearing

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 7500
  2. Radial Dynamic Load Rating Cr (N) 13400
  3. Basic static load rating, radial (C 0r) "7500.0000"
  4. Load carrying capacity (housing) (C 0r G) "12100.0000"
  5. ECLASS number 23-05-16-02
  6. ECLASS2 number 23-05-16-02
  7. Medias description Flanged housing unit RCJY..-TV-VA

Downloads and links

  1. Link to manufacturer Link to manufacturer
Show all details Show less
