RCJTY45-TV-VA-HLA INA

Housing unit

Stock
10 pcs in stock and ready for shipment
Brand INA
Article number RCJTY45-TV-VA-HLA INA
Inside diameter 45,00mm
Outside diameter 0,00mm
Width 0,00mm
Product description

The RCJTY45-TV-VA-HLA INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJTY45-TV-VA-HLA INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 45,00
  2. Outer (D) MM 0,00
  3. Width (B) MM 0,00
  4. Inner (d) Inch 1.7717
  5. Outer (D) Inch 0.0000
  6. Width (B) Inch 0.0000
  7. Flange width (L) mm 108,00
  8. Height flange (H) mm 188,00
  9. Total height unit (U) mm 54,20

Suffix description

  1. TV Plastic Housing
  2. VA Stainless Steel
  3. HLA Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

  1. Availability 10 pcs
  2. Brand INA
  3. Item number RCJTY45-TV-VA-HLA INA
  4. Also known as 0517634350000
    RCJTY45-TV-VA
  5. EAN 4054366715401
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.05

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment Stainless Steel Bearing

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 19400
  2. Radial Dynamic Load Rating Cr (N) 31500
  3. Basic static load rating, radial (C 0r) "19400.0000"
  4. Load carrying capacity (housing) (C 0r G) "15100.0000"
  5. ECLASS number 23-05-16-02
  6. ECLASS2 number 23-05-16-02
  7. Medias description Flanged housing unit RCJTY..-TV-VA
