RCJTY30-TV-VA-HLA INA

Housing and Bearing (assembly)

Stock
21 pcs in stock and ready for shipment
Brand INA
Article number RCJTY30-TV-VA-HLA INA
Inside diameter 30mm
Outside diameter 146mm
Width 40,9mm
Product description

The RCJTY30-TV-VA-HLA INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJTY30-TV-VA-HLA INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 146
  3. Width (B) MM 40,9
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 5.748
  6. Width (B) Inch 1.6102
  7. Flange width (L) mm 80
  8. Height flange (H) mm 148
  9. Total height unit (U) mm 40,2

Suffix description

  1. TV Plastic Housing
  2. VA Stainless Steel
  3. HLA Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

  1. Availability 21 pcs
  2. Brand INA
  3. Item number RCJTY30-TV-VA-HLA INA
  4. Also known as 0517325560000
    127565
    C2F30SS
    F2BC30M-TPSS
    F2B-SCEZ-30M-PCR
    F-UC206D1/LP03+FLR206D1
    F-UCFLR206/LP03
    MRC.C2F30SS
    MUC206 + NFL206SB
    MUCD206
    PSFT30CR
    RCJTY30TN VA
    RCJTY30-TV-VA
    UC206S6 + VFL206
    UCVFL206S6
    YAR206-2RF/HV + FYTWK506Y
  5. EAN 4054366714978
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.44

Product Properties

  1. Seal 2GU
  2. Lubrication Food Grease
  3. Special Treatment Stainless Steel Bearing

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 10700
  2. Radial Dynamic Load Rating Cr (N) 18700
  3. Load carrying capacity (housing) (C 0r G) 14200
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Flanged housing unit RCJTY..-TV-VA

Downloads and links

  1. Link to manufacturer Link to manufacturer
Show all details Show less
