RCJTY25-TV-VA-HLA INA

€ 85,38 ex VAT
€ 103,31 in VAT
€ 103,31 in VAT
€ 85,38 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CEST)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

RCJTY25-TV-VA-HLA INA

Housing unit

Stock
36 pcs in stock and ready for shipment
Brand INA
Article number RCJTY25-TV-VA-HLA INA
Inside diameter 25mm
Outside diameter 128mm
Width 37mm
Product description

The RCJTY25-TV-VA-HLA INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Help with this product

Downloads and links

Similar to: RCJTY25-TV-VA-HLA INA

Product
Dimensions/Properties
Stock
Price ex VAT
PSFT25CR RHP
PSFT25CR RHP
Guaranteed same day shipment on orders placed before 18:00h (CET)
€ 67,47 ex VAT
  • Inside diameter 25mm
  • Outside diameter 128mm
  • Width 37mm
PSFT25CR RHP
Guaranteed same day shipment on orders placed before 18:00h (CET)

6 pcs
€ 67,47 ex VAT
F2BC25M-TPSS SKF
F2BC25M-TPSS SKF
Guaranteed same day shipment on orders placed before 18:00h (CET)
€ 109,97 ex VAT
  • Inside diameter 25mm
  • Outside diameter 128mm
  • Width 37mm
F2BC25M-TPSS SKF
Guaranteed same day shipment on orders placed before 18:00h (CET)

2 pcs
€ 109,97 ex VAT
F2B-SCEZ-25M-PCR Dodge
F2B-SCEZ-25M-PCR Dodge
Guaranteed same day shipment on orders placed before 18:00h (CET)
€ 89,77 ex VAT
  • Inside diameter 25mm
  • Outside diameter 128mm
  • Width 37mm
F2B-SCEZ-25M-PCR Dodge
Guaranteed same day shipment on orders placed before 18:00h (CET)

12 pcs
€ 89,77 ex VAT

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 128
  3. Width (B) MM 37
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 5.0394
  6. Width (B) Inch 1.4567
  7. Flange width (L) mm 70
  8. Height flange (H) mm 130
  9. Total height unit (U) mm 36,8

Suffix description

  1. TV Plastic Housing
  2. VA Stainless Steel
  3. HLA Factory Location Code, No Additional Meaning. Can Be Used As Standard

Technical details

  1. Availability 36 pcs
  2. Brand INA
  3. Item number RCJTY25-TV-VA-HLA INA
  4. Also known as 0517325210000
    127564
    C2F25SS
    F2BC25M-TPSS
    F2B-SCEZ-25M-PCR
    F-UC205D1/LP03+FLR205D1
    F-UCFLR205/LP03
    MRC.C2F25SS
    MUC205 + NFL205SB
    MUCD205
    PSFT25CR
    RCJTY25-TV-VA
    UC205S6 + VFL205
    UCVFL205S6
    YAR205-2RF/HV + FYTWK505Y
  5. EAN 4054366714961
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.29

Product Properties

  1. Seal 2GU
  2. Lubrication Food Grease
  3. Special Treatment Stainless Steel Bearing

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 7500
  2. Radial Dynamic Load Rating Cr (N) 13400
  3. Load carrying capacity (housing) (C 0r G) 11100
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Flanged housing unit RCJTY..-TV-VA
