RCJT70-XL INA

€ 225,71 ex VAT
€ 273,11 in VAT
€ 273,11 in VAT
€ 225,71 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CEST)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

RCJT70-XL INA

Housing and Bearing (assembly)

Stock
43 pcs in stock and ready for shipment
Brand INA
Article number RCJT70-XL INA
Product description

The RCJT70-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJT70-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 70
  2. Outer (D) MM 258
  3. Width (B) MM 82,6
  4. Inner (d) Inch 2.7559
  5. Outer (D) Inch 10.1575
  6. Width (B) Inch 3.252
  7. Flange width (L) mm 160
  8. Height flange (H) mm 258
  9. Total height unit (U) mm 82,6

Suffix description

  1. XL X-Life

Technical details

  1. Availability 43 pcs
  2. Brand INA
  3. Item number RCJT70-XL INA
  4. Also known as 0008774330000
    GE70KRRB + CJT13/14
  5. EAN 4012802795271
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 6.15

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 44000
  2. Radial Dynamic Load Rating Cr (N) 66000
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Housing units RCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, R seals

Downloads and links

  1. Download datasheet Download datasheet
  2. Link to Manufacturer Link to Manufacturer
  3. X-life brochure X-life brochure
Show all details Show less
