RCJT40-XL-FA164 INA

Housing and Bearing (assembly)

Stock
3 pcs in stock and ready for shipment
Brand INA
Article number RCJT40-XL-FA164 INA
Inside diameter 40mm
Product description

The RCJT40-XL-FA164 INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJT40-XL-FA164 INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 40
  2. Inner (d) Inch 1.5748
  3. Flange width (L) mm 105
  4. Height flange (H) mm 172
  5. Total height unit (U) mm 59,1

Suffix description

  1. XL X-Life
  2. FA164 High Temperature Design Up To +250°C

Technical details

  1. Availability 3 pcs
  2. Brand INA
  3. Item number RCJT40-XL-FA164 INA
  4. Also known as 0004868680000
    RCJT40-FA164
  5. EAN 4012802784909
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.68

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment E - High Temp Design Up to +250°C

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 19800
  2. Radial Dynamic Load Rating Cr (N) 34500
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Housing units RCJT..-FA164, two-bolt flanged housing units, cast iron, eccentric locking collar, R seals, for temperatures up to +250°C

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
Show all details Show less
