RCJT17-XL INA

€ 36,10 ex VAT
€ 43,68 incl. VAT
€ 43,68 incl. VAT
€ 36,10 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CEST)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

RCJT17-XL INA

Housing unit

Stock
296 pcs in stock and ready for shipment
Brand INA
Article number RCJT17-XL INA
Inside diameter 17,00mm
Outside diameter 57,00mm
Width 40,40mm
Product description

The RCJT17-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RCJT17-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 17,00
  2. Outer (D) MM 57,00
  3. Width (B) MM 40,40
  4. Inner (d) Inch 0.6693
  5. Outer (D) Inch 2.2441
  6. Width (B) Inch 1.5906
  7. Flange width (L) mm 57,00
  8. Height flange (H) mm 99,00
  9. Total height unit (U) mm 40,40

Suffix description

  1. XL X-Life

Technical details

  1. Availability 296 pcs
  2. Brand INA
  3. Item number RCJT17-XL INA
  4. Also known as 0008308360000
    FYTB17WF
    GE17KRRB + CJT03
    RCJT17
    YEL203 + FYTB503M
  5. EAN 4012802792201
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.43

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 4750
  2. Radial Dynamic Load Rating Cr (N) 10100
  3. Basic static load rating, radial (C 0r) "4750.0000"
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Housing units RCJT, two-bolt flanged housing units, cast iron, eccentric locking collar, R seals
