RATRY35-XL INA

Housing and Bearing (assembly)

Stock
16 pcs in stock and ready for shipment
Brand INA
Article number RATRY35-XL INA
Inside diameter 35mm
Outside diameter 122mm
Width 33mm
Product description

The RATRY35-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RATRY35-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 35
  2. Outer (D) MM 122
  3. Width (B) MM 33
  4. Inner (d) Inch 1.378
  5. Outer (D) Inch 4.8031
  6. Width (B) Inch 1.2992
  7. Height flange (H) mm 122
  8. Total height unit (U) mm 28

Suffix description

  1. XL X-Life

Technical details

  1. Availability 16 pcs
  2. Brand INA
  3. Item number RATRY35-XL INA
  4. Also known as 0009640770000
    B7 + PFT7
    BPFT7
    GAY35NPPB + FLAN72MSTR
    PFD35RM
    RATRY35
    YAT207 + PFD72
  5. EAN 4012802822724
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.54

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 15300
  2. Radial Dynamic Load Rating Cr (N) 27500
  3. Load carrying capacity (housing) (C 0r G) 6400
  4. Load carrying capacity (housing) (C g) 6400
  5. ECLASS number 23-05-16-02
  6. ECLASS2 number 23-05-16-02
  7. Medias description Housing units RATRY, three-bolt flanged housing units, sheet steel, grub screws in inner ring, P seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
Show all details Show less
