RASEY50-XL-N-I INA

€ 60,68 ex VAT
€ 73,42 in VAT
€ 73,42 in VAT
€ 60,68 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

RASEY50-XL-N-I INA

Housing unit

Stock
40 pcs available for shipment on Fri 2 Jan
Brand INA
Article number RASEY50-XL-N-I INA
Inside diameter 50mm
Outside diameter 200mm
Width 54mm
Product description

The RASEY50-XL-N-I INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RASEY50-XL-N-I INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 50
  2. Outer (D) MM 200
  3. Width (B) MM 54

Suffix description

  1. XL X-Life
  2. N Cast Iron Housing With Undercut Slot For End Caps
  3. I Inch Size Grease Nipple R 1/8”

Technical details

  1. Availability 40 pcs on Fri 2 Jan
  2. Brand INA
  3. Item number RASEY50-XL-N-I INA
  4. Also known as 0008583230000
    NIP DIN71412-A R 1/8
    NIP DIN71412-B R 1/8
    NIP DIN71412-C R 1/8
    RASEY50-N
    RASEY50-XL-N
  5. EAN 4012802797930
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 2.6

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. ECLASS number 23-05-16-01
  2. ECLASS2 number 23-05-16-01
  3. Medias description Plummer block housing units RASEY, cast iron housing, radial insert ball bearing with grub screws in inner ring, R seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
Show all details Show less
