RAE35-XL-NPP-NR INA

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 72
3. Width (B) MM 39
4. Inner (d) Inch 1.378
5. Outer (D) Inch 2.8346
6. Width (B) Inch 1.5354
7. Width (b) mm 25,4
8. Locking collar total width (B 1) mm 39

Suffix description

1. XL X-Life
2. NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)
3. NR Slot And Snap Ring For Radial Insert Ball Bearings With Cylindrical Outer Ring

Technical details

1. Availability 1 pc
2. Brand INA
3. Item number RAE35-XL-NPP-NR INA
4. Also known as 0009732460000
   RAE35-NPP-NR

5. EAN 4012802820812
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.53

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Non-Regreaseable
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 15300
2. Radial Dynamic Load Rating Cr (N) 27500
3. Basic static load rating, radial (C 0r) "15300.0000"
4. ECLASS number 23-05-08-02
5. ECLASS2 number 23-05-08-02
6. Medias description Radial insert ball bearings RAE..-NPP-NR, cylindrical outer ring, location by eccentric locking collar, slots in outer ring, P seals on both sides
