RAE15-NPP INA

All dimensions

1. Inner (d) MM 15
2. Outer (D) MM 40
3. Width (B) MM 28,6
4. Inner (d) Inch 0.5906
5. Outer (D) Inch 1.5748
6. Width (B) Inch 1.126
7. Width (b) mm 19
8. Locking collar total width (B 1) mm 28,6

Suffix description

1. NPP Lip Seals On Both Sides (P Type - Two Zinc-Plated Sheet Steel Washers With Intermediate NBR Part, Seal Lip Axially Preloaded)

Technical details

1. Availability 5 pcs
2. Brand INA
3. Item number RAE15-NPP INA
4. Also known as 0008501440000
   RAE15-NPP-FA106
   YET203/15CW

5. EAN 4012802800371
6. Category Bearings for Housings

Weight and Dimensions

1. Weight (kg) 0.1185

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 4750
2. Radial Dynamic Load Rating Cr (N) 10100
3. ECLASS number 23-05-08-02
4. ECLASS2 number 23-05-08-02
5. Medias description Radial insert ball bearing RAE..-NPP
