RA50-XL INA

Housing and Bearing (assembly)

Stock
47 pcs in stock and ready for shipment
Brand INA
Article number RA50-XL INA
Inside diameter 50mm
Outside diameter 155mm
Width 36,7mm
Product description

The RA50-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RA50-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 50
  2. Outer (D) MM 155
  3. Width (B) MM 36,7
  4. Inner (d) Inch 1.9685
  5. Outer (D) Inch 6.1024
  6. Width (B) Inch 1.4449
  7. Height flange (H) mm 155,5
  8. Locking collar total width (B 1) mm 43,8
  9. Total height unit (U) mm 36,7

Suffix description

  1. XL X-Life

Technical details

  1. Availability 47 pcs
  2. Brand INA
  3. Item number RA50-XL INA
  4. Also known as 0008293660000
    RA50
  5. EAN 4012802792607
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.68

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 23200
  2. Radial Dynamic Load Rating Cr (N) 37500
  3. Load carrying capacity (housing) (C 0r G) 8600
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Flanged housing unit RA..-XL
