QJ348-N2-MPA FAG

The QJ348-N2-MPA FAG is a four point contact ball bearing with a brass cage (centered on outer ring) and no seal.

Stock
not in stock
Brand FAG
Article number QJ348-N2-MPA FAG
Inside diameter 240mm
Outside diameter 500mm
Width 95mm
Product description
Four point contact bearings QJ3..-N2, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
Read more Show less
Help with this product

Downloads

Similar to: QJ348-N2-MPA FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 240
  2. Outer (D) MM 500
  3. Width (B) MM 95

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number QJ348-N2-MPA FAG
  4. Technical details (N2-MPA) N2=(Segment 'Ext. Modif.', Code N2)=Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer. MPA=(MA-Cage Type Segment)=Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing).
  5. Category Four Point Contact Ball Bearing
  6. Description from Medias Four point contact bearings QJ3..-N2, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
  7. Weight (kg) 98.20
  8. Manufacturer Part Number (MPN) QJ348-N2-MPA
  9. Seal No Seal
  10. Cage Type MA - Brass Cage, Centered on Outer Ring
  11. External Modification N2 - 2 Locking Groove in Outer Ring
  12. Radial Internal Play Cn Normal Internal
  13. Precision Standard Precision
  14. Heat Stabilization No Heat Stabilization - Temperatures up to 120°C
  15. Split Innering / Outerring Split innerring
