QJ318N2 MPA Neutral

All dimensions

1. Inner (d) MM 90
2. Outer (D) MM 190
3. Width (B) MM 43

Suffix description

1. N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
2. MPA Solid Brass Cage

Technical details

1. Availability 0 pcs
2. Brand Neutral
3. Item number QJ318N2 MPA Neutral
4. Category Four Point Contact Ball Bearing

Weight and Dimensions

1. Weight (kg) 6.3

Product Properties

1. Seal No Seal
2. Cage Type MA - Brass Cage, Centered on Outer Ring
3. External Modification N2 - 2 Locking Groove in Outer Ring
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
7. Split Inner ring / Outer ring Split inner ring
