QJ317-N2-MPA FAG

The QJ317-N2-MPA FAG is a four point contact ball bearing with a brass cage (centered on outer ring) and no seal.

Stock
25 pcs in stock and ready for shipment
Brand FAG
Article number QJ317-N2-MPA FAG
Inside diameter 85mm
Outside diameter 180mm
Width 41mm
Product description
Four point contact bearings QJ3..-N2, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
Read more Show less
Help with this product

Downloads

Similar to: QJ317-N2-MPA FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 85
  2. Outer (D) MM 180
  3. Width (B) MM 41

Technical details

  1. Availability 25 pcs
  2. Brand FAG
  3. Item number QJ317-N2-MPA FAG
  4. Technical details (N2-MPA) N2=(Segment 'Ext. Modif.', Code N2)=Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer. MPA=(MA-Cage Type Segment)=Window-Type Machined Brass Cage; Guidance By The Outer Ring (Housing).
  5. Also known as 4012801268349
  6. Category Four Point Contact Ball Bearing
  7. Description from Medias Four point contact bearings QJ3..-N2, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
  8. Weight (kg) 5.28
  9. Manufacturer Part Number (MPN) QJ317-N2-MPA
  10. Seal No Seal
  11. Cage Type MA - Brass Cage, Centered on Outer Ring
  12. External Modification N2 - 2 Locking Groove in Outer Ring
  13. Radial Internal Play Cn Normal Internal
  14. Precision Standard Precision
  15. Heat Stabilization No Heat Stabilization - Temperatures up to 120°C
  16. Split Innering / Outerring Split innerring
