QJ218-XL-N2-TVP FAG

All dimensions

1. Inner (d) MM 90
2. Outer (D) MM 160
3. Width (B) MM 50
4. Inner (d) Inch 3.5433
5. Outer (D) Inch 6.2992
6. Width (B) Inch 1.9685
7. Width (b) mm 30

Suffix description

1. XL X-Life
2. N2 Two Locating Slots (Notches) 180° Apart In One Outer Ring Side Face Or Housing Washer
3. TVP Moulded Polyamide Window-Type Cage, Rolling Element Riding

Technical details

1. Availability 12 pcs
2. Brand FAG
3. Item number QJ218-XL-N2-TVP FAG
4. Also known as 0192610710000
   QJ218-N2-TVP

5. EAN 4012801267632
6. Category Four Point Contact Ball Bearing

Weight and Dimensions

1. Weight (kg) 2.35

Product Properties

1. Seal No Seal
2. Cage Type P - Plastic Molded Cage
3. External Modification N2 - 2 Locking Groove in Outer Ring
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
7. Split Inner ring / Outer ring Split inner ring

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 198000
2. Radial Dynamic Load Rating Cr (N) 189000
3. Limiting speed (n G) 5500
4. Reference speed (n ϑr) 3750
5. ECLASS number 23-05-08-03
6. ECLASS2 number 23-05-08-03
7. Medias description Four point contact bearings QJ2..-N2, main dimensions to DIN 628-4, can be dismantled, with split inner ring, with two retaining slots
