QJ214N2MA NSK

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 125
3. Width (B) MM 24
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 4.9213
6. Width (B) Inch 0.9449

Suffix description

1. N2 Two Locating Slots (Notches), 180° Apart In One Outer Ring Side Face Or Housing Washer
2. MA Machined Brass Cage Guidance By The Outer Ring

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number QJ214N2MA NSK
4. Also known as QJ214-N2-MPA
   QJ214-XL-N2-MPA

5. Category Four Point Contact Ball Bearing

Weight and Dimensions

1. Weight (kg) 1.3

Product Properties

1. Seal No Seal
2. Cage Type MA - Brass Cage, Centered on Outer Ring
3. External Modification N2 - 2 Locking Groove in Outer Ring
4. Radial Internal Play Cn Normal Internal Play
5. Precision Standard Precision
6. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
7. Split Inner ring / Outer ring Split inner ring
