PWTR40-2RS-A INA

Yoke type full complement track roller with cylindrical rollers

Stock
not in stock
Brand INA
Article number PWTR40-2RS-A INA
Inside diameter 40mm
Outside diameter 80mm
Width 30mm
Product description

The PWTR40-2RS-A INA is a track roller or support roller with cylindrical rollers. These rolling elements combine a high load capacity with reasonable shock resistance. Track rollers are designed for use with various types of tracks. Thanks to a thick-walled outer ring, they can withstand high radial loads. Axial loads due to alignment errors or misalignment can be absorbed in both directions. Yoke type track rollers are suitable for mounting on a shaft. They are not mounted in a housing bore, but a flat (counter) track provides support.

The PWTR40-2RS-A INA has a full complement design. The absence of a cage allows for a greater number of rolling elements, making this track roller radially highly loadable. Full complement track rollers are also more shock-resistant than track rollers with a cage. However, the maximum rotational speed is lower than that of caged variants. Common applications of track rollers include conveyor systems, linear guidance systems, and cam mechanisms.

Read more Show less
Help with this product

Similar to: PWTR40-2RS-A INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 40
  2. Outer (D) MM 80
  3. Width (B) MM 30
  4. Inner (d) Inch 1.5748
  5. Outer (D) Inch 3.1496
  6. Width (B) Inch 1.1811

Suffix description

  1. 2RS Rubber Seals At Each Side Of The Bearing, Temperature Range -30 ~ 120℃
  2. A Alteration In Internal Construction. Identical To Old Notation

Technical details

  1. Availability 0 pcs
  2. Brand INA
  3. Item number PWTR40-2RS-A INA
  4. Category Support Roller

Weight and Dimensions

  1. Weight (kg) 0.816

Product Properties

  1. Seal 2RS - Rubber Seal on Two Sides
  2. Running Surface Standard
