PR14135-PP-GR1/0-10 INA

All dimensions

1. Inner (d) MM 0,00
2. Outer (D) MM 76,20
3. Width (B) MM 198,00
4. Inner (d) Inch 0.0000
5. Outer (D) Inch 3.0000
6. Width (B) Inch 7.7953
7. Height (H) mm 57,20
8. Length total (L tot) mm 217,90
9. Width (b) mm 76,20

Suffix description

1. PP Lip Seal On Both Sides Of Bearing
2. GR1
3. /0-10 Micron

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number PR14135-PP-GR1/0-10 INA
4. Also known as 0016138980001

5. EAN 4054366020871
6. Category Linear Plain Bearing

Weight and Dimensions

1. Weight (kg) 5.65

Product Properties

1. Seal 2L - LS-seal at Both Sides

Data from Schaeffler (medias)

1. Load capacity dyn. (C) "435000.0000"
2. Load capacity static (C 0) "345000.0000"
3. ECLASS number 23-30-90-90
4. ECLASS2 number 23-30-90-90
5. Medias description Linear roller bearings, inch size mounting dimensions, PR..-PP
