PNA22/44-XL INA

All dimensions

1. Inner (d) MM 22
2. Outer (D) MM 44
3. Width (B) MM 20
4. Inner (d) Inch 0.8661
5. Outer (D) Inch 1.7323
6. Width (B) Inch 0.7874

Suffix description

1. XL X-Life

Technical details

1. Availability 3 pcs
2. Brand INA
3. Item number PNA22/44-XL INA
4. Also known as 0507802710000
   PNA22/44

5. EAN 4012802735925
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.14

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 34000
2. Radial Dynamic Load Rating Cr (N) 24800
3. Limiting speed (n G) 15800
4. ECLASS number 23-05-09-07
5. ECLASS2 number 23-05-09-07
6. Medias description Aligning needle roller bearings PNA, with inner ring
