PHEY45-XL INA

Housing and Bearing (assembly)

Stock
20 pcs available for shipment on Tue 23 Dec
Brand INA
Article number PHEY45-XL INA
Inside diameter 45mm
Outside diameter 145mm
Width 110mm
Product description

The PHEY45-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: PHEY45-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 45
  2. Outer (D) MM 145
  3. Width (B) MM 110
  4. Inner (d) Inch 1.7717
  5. Outer (D) Inch 5.7087
  6. Width (B) Inch 4.3307
  7. Length total (L) mm 145
  8. Housing total width (M) mm 110
  9. Width housing (A 2) mm 40

Suffix description

  1. XL X-Life

Technical details

  1. Availability 20 pcs on Tue 23 Dec
  2. Brand INA
  3. Item number PHEY45-XL INA
  4. Also known as 0009492990000
    GAY45NPPB + HE09
    PHEY45
  5. EAN 4012802802146
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.75

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. ECLASS number 23-05-16-03
  2. ECLASS2 number 23-05-16-03
  3. Medias description Take-up housing units PHEY, cast iron housing, radial insert ball bearing with grub screws in inner ring, P seals
