PHEY25-XL INA

Name: PHEY25-XL INA
Brand: INA

€ 30,14 ex VAT

€ 36,47 in VAT

€ 30,14 ex VAT

	Guaranteed same day shipment on orders placed before 18.00h (CET)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

PHEY25-XL INA

Housing and Bearing (assembly)

Stock	126 pcs in stock and ready for shipment
Brand	INA
Article number	PHEY25-XL INA
Inside diameter	25mm
Outside diameter	99mm
Width	70mm

Product description

The PHEY25-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Email us at: help@247industries.com Response within 24h

Downloads and links

Similar to: PHEY25-XL INA

Loading similair products

Product specifications

Inside diameter 25mm
Outside diameter 99mm
Width 70mm

All dimensions

Inner (d) MM 25
Outer (D) MM 99
Width (B) MM 70
Inner (d) Inch 0.9843
Outer (D) Inch 3.8976
Width (B) Inch 2.7559
Length total (L) mm 99
Housing total width (M) mm 70
Width housing (A 2) mm 28

Suffix description

XL X-Life

Technical details

Availability 126 pcs
Brand INA
Item number PHEY25-XL INA
Also known as 0009200610000
GAY25NPPB + HE05
PHEY25
EAN 4012802806267
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 0.68

Product Properties

Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

ECLASS number 23-05-16-03
ECLASS2 number 23-05-16-03
Medias description Take-up housing units PHEY, cast iron housing, radial insert ball bearing with grub screws in inner ring, P seals
