PHE25-XL INA

Name: PHE25-XL INA
Brand: INA

€ 35,72 ex VAT

€ 43,22 in VAT

€ 35,72 ex VAT

	Guaranteed same day shipment on orders placed before 18.00h (CEST)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

PHE25-XL INA

Housing and Bearing (assembly)

Stock	219 pcs in stock and ready for shipment
Brand	INA
Article number	PHE25-XL INA

Product description

The PHE25-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Email us at: help@247industries.com Response within 24h

Downloads and links

Similar to: PHE25-XL INA

Loading similair products

Product specifications

All dimensions

Inner (d) MM 25
Outer (D) MM 99
Width (B) MM 70
Inner (d) Inch 0.9843
Outer (D) Inch 3.8976
Width (B) Inch 2.7559
Length total (L) mm 99
Housing total width (M) mm 70
Width housing (A 2) mm 28

Suffix description

XL X-Life

Technical details

Availability 219 pcs
Brand INA
Item number PHE25-XL INA
Also known as 0008408070000
PHE25
EAN 4012802788389
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 0.71

Product Properties

Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

ECLASS number 23-05-16-03
ECLASS2 number 23-05-16-03
Medias description Take-up housing units PHE, cast iron housing, radial insert ball bearing with eccentric locking collar, P seals
