PCSLT30-XL INA

€ 25,54 ex VAT
€ 30,90 in VAT
€ 30,90 in VAT
€ 25,54 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

PCSLT30-XL INA

Housing and Bearing (assembly)

Stock
8 pcs in stock and ready for shipment
Brand INA
Article number PCSLT30-XL INA
Inside diameter 30mm
Outside diameter 112,5mm
Width 29mm
Product description

The PCSLT30-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: PCSLT30-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 112,5
  3. Width (B) MM 29
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 4.4291
  6. Width (B) Inch 1.1417
  7. Flange width (L) mm 84
  8. Height flange (H) mm 112,5
  9. Total height unit (U) mm 29

Suffix description

  1. XL X-Life

Technical details

  1. Availability 8 pcs
  2. Brand INA
  3. Item number PCSLT30-XL INA
  4. Also known as 0009748970000
    PCSLT30
    RALE30NPPB + 55CSLT/CST
  5. EAN 4012802819960
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.38

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 8300
  2. Radial Dynamic Load Rating Cr (N) 14100
  3. Load carrying capacity (housing) (C 0r G) 6000
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Housing units PCSLT, two-bolt flanged housing units, sheet steel, eccentric locking collar, P seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
