PCJT25-TV-FA125.5 INA

€ 44,67 ex VAT
€ 54,06 in VAT
€ 54,06 in VAT
€ 44,67 ex VAT

Guaranteed same day shipment on orders placed before 18.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

PCJT25-TV-FA125.5 INA

Housing and Bearing (assembly)

Stock
33 pcs available
Brand INA
Article number PCJT25-TV-FA125.5 INA
Inside diameter 25mm
Outside diameter 130mm
Width 40,5mm
Product description

The PCJT25-TV-FA125.5 INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: PCJT25-TV-FA125.5 INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 130
  3. Width (B) MM 40,5
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 5.1181
  6. Width (B) Inch 1.5945
  7. Flange width (L) mm 70
  8. Height flange (H) mm 130
  9. Total height unit (U) mm 40,5

Suffix description

  1. TV Plastic Housing
  2. FA125,5 With Corrotect® Coating, Protected Against Corrosion

Technical details

  1. Availability 33 pcs
  2. Brand INA
  3. Item number PCJT25-TV-FA125.5 INA
  4. Also known as 0573386200000
  5. EAN 4012802831795
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.33

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment With Corrotect® Coating

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 7800
  2. Radial Dynamic Load Rating Cr (N) 14900
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Flanged housing unit PCJT..-TV

Downloads and links

  1. Link to manufacturer Link to manufacturer
Show all details Show less
