PCJ35-XL-N-FA125 INA

Housing and Bearing (assembly)

Stock
3 pcs in stock and ready for shipment
Brand INA
Article number PCJ35-XL-N-FA125 INA
Inside diameter 35mm
Outside diameter 118mm
Width 50,5mm
Product description

The PCJ35-XL-N-FA125 INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: PCJ35-XL-N-FA125 INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 35
  2. Outer (D) MM 118
  3. Width (B) MM 50,5
  4. Inner (d) Inch 1.378
  5. Outer (D) Inch 4.6457
  6. Width (B) Inch 1.9882
  7. Flange width (L) mm 118
  8. Total height unit (U) mm 50,5

Suffix description

  1. XL X-Life
  2. N Cast Iron Housing With Undercut Slot For End Caps
  3. FA125 With Corrotect® Coating, Protected Against Corrosion

Technical details

  1. Availability 3 pcs
  2. Brand INA
  3. Item number PCJ35-XL-N-FA125 INA
  4. Also known as 0096273160000
    PCJ35-N-FA125
  5. EAN 4012802810424
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.46

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment With Corrotect® Coating

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 15300
  2. Radial Dynamic Load Rating Cr (N) 27500
  3. ECLASS number 23-05-16-02
  4. ECLASS2 number 23-05-16-02
  5. Medias description Housing units PCJ..-FA125, four-bolt flanged housing units, cast iron, eccentric locking collar, P seals, with anti-corrosion protection
