NX30-XL INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 42
3. Width (B) MM 30
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.6535
6. Width (B) Inch 1.1811
7. Height (C) mm 30

Suffix description

1. XL X-Life

Technical details

1. Availability 35 pcs on Mon 31 Aug
2. Brand INA
3. Item number NX30-XL INA
4. Also known as 0507786170000
   NX30

5. EAN 4012802703542
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.13

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 36000
2. Radial Dynamic Load Rating Cr (N) 25500
3. Axial Static Load Rating C0a (N) 28000
4. Axial Dynamic Load Rating Ca (N) 11700
5. Limiting speed (n G) 4300
6. ECLASS number 23-05-12-02
7. ECLASS2 number 23-05-12-02
8. Medias description Needle roller/axial ball bearings NX, single direction axial component, for oil lubrication
