NU2356-EX-TB-M1 FAG

The NU2356-EX-TB-M1 FAG bearing is a single row cylindrical roller bearing with a brass cage, a cylindrical bore and no seal.

Stock
not in stock
Brand FAG
Article number NU2356-EX-TB-M1 FAG
Inside diameter 280mm
Outside diameter 580mm
Width 175mm
Product description
Cylindrical roller bearings NU23..-E, main dimensions to DIN 5412-1, non-locating bearing, separable, with cage
Read more Show less
Help with this product

Downloads

Similar to: NU2356-EX-TB-M1 FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 280
  2. Outer (D) MM 580
  3. Width (B) MM 175
  4. Inner (d) Inch -
  5. Outer (D) Inch -
  6. Width (B) Inch -

Technical details

  1. Availability 0 pcs
  2. Brand FAG
  3. Item number NU2356-EX-TB-M1 FAG
  4. Technical details (EX-TB-M1) EX=Increased Capacity Design, Design Modified In Accordance With Standard (Parts From These Bearings Must Not Be Interchanged With Parts From Bearings Of The Same Size Of The Previous Design E). TB=The Rollers Have A Special Crowning On The Side Surface. Is Not Depending On The Cage Design. The Result Is A Better Lubrication In Between Roller And Rim. M1=Solid Brass Cage, Two Piece, Roller Guided.
  5. Category Cylindrical Roller Bearing Single Row
  6. Description from Medias Cylindrical roller bearings NU23..-E, main dimensions to DIN 5412-1, non-locating bearing, separable, with cage
  7. Weight (kg) 235
  8. Manufacturer Part Number (MPN) NU2356-EX-TB-M1
  9. Bore C - Cylindrical Bore
  10. Seal No Seal
  11. Cage Type M - Brass Cage
  12. External Modification No Pairing
  13. Radial Internal Play Cn Normal Internal
  14. Precision Standard Precision
  15. Heat Stabilization No Heat Stabilization - Temperatures up to 120°C
