NU2305ECJ ISB

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 62
3. Width (B) MM 24
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.9449

Suffix description

1. EC Single Row Cylindrical Roller Bearing With An Optimized Internal Design And With Modified Roller End/Flange Contact
2. J Pressed Steel Cage, Rolling Element Centered, Unhardened

Technical details

1. Availability 26 pcs
2. Brand ISB
3. Item number NU2305ECJ ISB
4. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.348

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
