NU2305E/MA6/C4 AKN

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 62
3. Width (B) MM 24
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.9449

Suffix description

1. E Increased Load Capacity
2. MA6 Outer Ring Guided Solid Brass Cage For Cylindrical Roller Bearings, Cage Body Designed With Trapezoid-Shaped Machined Rivets
3. C4 Bearing Internal Clearance Greater Than C3

Technical details

1. Availability 0 pcs
2. Brand AKN
3. Item number NU2305E/MA6/C4 AKN
4. Also known as NU2305-E-M1A-C4
   NU2305-E-XL-M1A-C4

5. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.382

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type MA - Brass Cage, Centered on Outer Ring
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
