NU2244-EX-TB-MCA-C4 FAG

All dimensions

1. Inner (d) MM 220
2. Outer (D) MM 400
3. Width (B) MM 108
4. Inner (d) Inch 8.6614
5. Outer (D) Inch 15.748
6. Width (B) Inch 4.252

Suffix description

1. EX Increased Capacity Design, Design Modified In Accordance With Standard (Parts From These Bearings Must Not Be Interchanged With Parts From Bearings Of The Same Size Of The Previous Design E)
2. TB The Rollers Have A Special Crowning On The Side Surface. Is Not Depending On The Cage Design. The Result Is A Better Lubrication In Between Roller And Rim
3. MCA Solid Brass Cage, Single-Piece, Guided On Outer Ring
4. C4 Bearing Internal Clearance Greater Than C3

Technical details

1. Availability 1 pc
2. Brand FAG
3. Item number NU2244-EX-TB-MCA-C4 FAG
4. Also known as 3013477000040
   NU2244-EX-TB-M1A-C4

5. EAN 4064328278141
6. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 60.6

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type MA - Brass Cage, Centered on Outer Ring
4. External Modification No External Modification
5. Radial Internal Play C4 Internal Play (Higher than C3)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
