NU209E G1 NTN

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 85
3. Width (B) MM 19
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 3.3465
6. Width (B) Inch 0.748

Suffix description

1. E Increased Load Capacity
2. G1 Machined Brass Cage For Cylindrical Roller Bearings, Rivetless

Technical details

1. Availability 0 pcs
2. Brand NTN
3. Item number NU209E G1 NTN
4. Also known as NU209ECM
   NU209EM
   NU209-E-M1
   NU209-E-XL-M1

5. Category Cylindrical Roller Bearing Single Row

Weight and Dimensions

1. Weight (kg) 0.478

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
