NNF5010PP 2NR IDC/Interprecise Donath GmbH

All dimensions

1. Inner (d) MM 50,00
2. Outer (D) MM 80,00
3. Width (B) MM 40,00
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 3.1496
6. Width (B) Inch 1.5748

Suffix description

1. PP Lip Seals On Both Sides Of The Bearing
2. 2NR Two Separately Included Snap Rings Type WRE

Technical details

1. Availability 0 pcs
2. Brand IDC/Interprecise Donath GmbH
3. Item number NNF5010PP 2NR IDC/Interprecise Donath GmbH
4. Also known as SL045010-PP-2NR

5. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.76

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2L - LS-seal at Both Sides
3. Cage Type FC - Full Complement, No Cage
4. External Modification 2R - 2 Snap Rings in O.D.
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
