NN3028-AS-M-SP FAG

All dimensions

1. Inner (d) MM 140,00
2. Outer (D) MM 210,00
3. Width (B) MM 53,00
4. Inner (d) Inch 5.5118
5. Outer (D) Inch 8.2677
6. Width (B) Inch 2.0866
7. Width (b) mm 53,00

Suffix description

1. A Cylindrical Roller Bearings, Parts Interchangeable
2. S Lubrication Groove And Three Holes In Bearing Outer Ring
3. M Solid Brass Cage, Roller Guided
4. SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1

Technical details

1. Availability 3 pcs
2. Brand FAG
3. Item number NN3028-AS-M-SP FAG
4. Also known as 0192313420000

5. EAN 4012801581653
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 6.16

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision SP - Precision Higher than P4S
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 520000
2. Radial Dynamic Load Rating Cr (N) 300000
3. Basic static load rating, radial (C 0r) "520000.0000"
4. Fatigue load limit, radial (C ur) "64000.0000"
5. Limiting speed for grease lubrication (n G Grease) "3900.0000"
6. Limiting speed for oil lubrication (n G Oil) "4600.0000"
7. ECLASS number 23-05-09-01
8. ECLASS2 number 23-05-09-01
9. Medias description Cylindrical roller bearing NN..-AS-M-SP, with cage, two-row, non-locating bearing, 0 ribs on outer ring (smooth), 3 ribs on inner ring, type NN
