NN3011-AS-K-M-SP FAG

All dimensions

1. Inner (d) MM 55,00
2. Outer (D) MM 90,00
3. Width (B) MM 26,00
4. Inner (d) Inch 2.1654
5. Outer (D) Inch 3.5433
6. Width (B) Inch 1.0236

Suffix description

1. A Cylindrical Roller Bearings, Parts Interchangeable
2. S Lubrication Groove And Three Holes In Bearing Outer Ring
3. K Tapered Bore, Taper 1:12
4. M Solid Brass Cage, Roller Guided
5. SP Super Precision Specification, Tolerance Class SP, Radial Clearance C1

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number NN3011-AS-K-M-SP FAG
4. Also known as 0167369310000

5. EAN 4012801017213
6. Category Cylindrical Roller Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.62

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Seal No Seal
3. Cage Type M - Brass Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision SP - Precision Higher than P4S
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
