NKX30-Z-XL INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 42
3. Width (B) MM 30
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.6535
6. Width (B) Inch 1.1811
7. Height (C) mm 30

Suffix description

1. Z Shield Of Pressed Sheet Steel On One Side Of The Bearing
2. XL X-Life

Technical details

1. Availability 101 pcs
2. Brand INA
3. Item number NKX30-Z-XL INA
4. Also known as 0507475920000
   NKX30-Z

5. EAN 4054364929121
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.148

Product Properties

1. Seal Z - Steel Seal on One Side

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 36000
2. Radial Dynamic Load Rating Cr (N) 25500
3. Axial Static Load Rating C0a (N) 42000
4. Axial Dynamic Load Rating Ca (N) 20400
5. Limiting speed (n G) 5000
6. ECLASS number 23-05-12-02
7. ECLASS2 number 23-05-12-02
8. Medias description Needle roller/axial ball bearings NKX..-Z, axial component, single direction, to DIN 5429, with end cap, for grease lubrication
