NKS70-XL INA

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 90
3. Width (B) MM 28
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 3.5433
6. Width (B) Inch 1.1024
7. Under roller diameter (F w) mm 70

Suffix description

1. XL X-Life

Technical details

1. Availability 59 pcs
2. Brand INA
3. Item number NKS70-XL INA
4. Also known as 0507701100000
   NKS70

5. EAN 4047643203760
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.38

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 113000
2. Radial Dynamic Load Rating Cr (N) 77000
3. Limiting speed (n G) 6400
4. Reference speed (n ϑr) 4200
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NKS, heavy series

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
