NKIS45-XL INA

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 72
3. Width (B) MM 22
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 2.8346
6. Width (B) Inch 0.8661
7. Width (b) mm 22

Suffix description

1. XL X-Life

Technical details

1. Availability 73 pcs
2. Brand INA
3. Item number NKIS45-XL INA
4. Also known as 0507710270000
   NKIS45

5. EAN 4012802734744
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.336

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 74000
2. Radial Dynamic Load Rating Cr (N) 51000
3. Limiting speed (n G) 8200
4. Limiting speed for grease lubrication (n G Grease) 4900
5. Reference speed (n ϑr) 4600
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NKIS, heavy series

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
