NKIS40-XL INA

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 65
3. Width (B) MM 22
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 2.5591
6. Width (B) Inch 0.8661
7. Width (b) mm 22

Suffix description

1. XL X-Life

Technical details

1. Availability 59 pcs
2. Brand INA
3. Item number NKIS40-XL INA
4. Also known as 0507710190000
   NKIS40

5. EAN 4054363051670
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.281

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 67000
2. Radial Dynamic Load Rating Cr (N) 48000
3. Limiting speed (n G) 8900
4. Limiting speed for grease lubrication (n G Grease) 5300
5. Reference speed (n ϑr) 4850
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NKIS, heavy series
