NKIS35-XL INA

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 58
3. Width (B) MM 22
4. Inner (d) Inch 1.378
5. Outer (D) Inch 2.2835
6. Width (B) Inch 0.8661
7. Width (b) mm 22

Suffix description

1. XL X-Life

Technical details

1. Availability 17 pcs
2. Brand INA
3. Item number NKIS35-XL INA
4. Also known as 0507710000000
   NKIS35

5. EAN 4012802702088
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.235

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 57000
2. Radial Dynamic Load Rating Cr (N) 44000
3. Limiting speed (n G) 10200
4. Limiting speed for grease lubrication (n G Grease) 6100
5. Reference speed (n ϑr) 5600
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NKIS, heavy series

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
