NKIB5906-XL INA

All dimensions

1. Inner (d) MM 30
2. Outer (D) MM 47
3. Width (B) MM 25
4. Inner (d) Inch 1.1811
5. Outer (D) Inch 1.8504
6. Width (B) Inch 0.9843
7. Width (b) mm 25

Suffix description

1. XL X-Life

Technical details

1. Availability 237 pcs
2. Brand INA
3. Item number NKIB5906-XL INA
4. Also known as 0507828780000
   NKIB5906

5. EAN 4012802736151
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.143

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 35500
2. Radial Dynamic Load Rating Cr (N) 28500
3. Axial Static Load Rating C0a (N) 11200
4. Axial Dynamic Load Rating Ca (N) 5900
5. Limiting speed (n G) 12700
6. Reference speed (n ϑr) 10000
7. ECLASS number 23-05-12-01
8. ECLASS2 number 23-05-12-01
9. Medias description Needle roller/angular contact ball bearings NKIB, double direction axial component
