NKIA5912-XL INA

All dimensions

1. Inner (d) MM 60
2. Outer (D) MM 85
3. Width (B) MM 34
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 3.3465
6. Width (B) Inch 1.3386
7. Width (b) mm 34

Suffix description

1. XL X-Life

Technical details

1. Availability 41 pcs
2. Brand INA
3. Item number NKIA5912-XL INA
4. Also known as 0504212390000
   NKIA5912

5. EAN 4012802731613
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.59

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 108000
2. Radial Dynamic Load Rating Cr (N) 68000
3. Axial Static Load Rating C0a (N) 32000
4. Axial Dynamic Load Rating Ca (N) 12400
5. Limiting speed (n G) 6800
6. Reference speed (n ϑr) 5500
7. ECLASS number 23-05-12-01
8. ECLASS2 number 23-05-12-01
9. Medias description Needle roller/angular contact ball bearings NKIA, single direction axial component, to DIN 5 429-2
