NKIA5901-XL INA

All dimensions

1. Inner (d) MM 12
2. Outer (D) MM 24
3. Width (B) MM 16
4. Inner (d) Inch 0.4724
5. Outer (D) Inch 0.9449
6. Width (B) Inch 0.6299
7. Width (b) mm 16

Suffix description

1. XL X-Life

Technical details

1. Availability 216 pcs
2. Brand INA
3. Item number NKIA5901-XL INA
4. Also known as 0504211150000
   NJA5901
   NKIA5901

5. EAN 4012802731491
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.0318

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 8300
2. Radial Dynamic Load Rating Cr (N) 8600
3. Axial Static Load Rating C0a (N) 3450
4. Axial Dynamic Load Rating Ca (N) 2700
5. Limiting speed (n G) 23600
6. Reference speed (n ϑr) 21000
7. ECLASS number 23-05-12-01
8. ECLASS2 number 23-05-12-01
9. Medias description Needle roller/angular contact ball bearings NKIA, single direction axial component, to DIN 5 429-2
