NKI90/36-XL INA

All dimensions

1. Inner (d) MM 90,00
2. Outer (D) MM 120,00
3. Width (B) MM 36,00
4. Inner (d) Inch 3.5433
5. Outer (D) Inch 4.7244
6. Width (B) Inch 1.4173
7. Width (b) mm 36,00

Suffix description

1. XL X-Life

Technical details

1. Availability 28 pcs
2. Brand INA
3. Item number NKI90/36-XL INA
4. Also known as 0507629150000
   NA9012036
   NBI9012036
   NKI90/36
   NKJ90/36A
   TAFI9012036

5. EAN 4012802702019
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 1.09

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 237000
2. Radial Dynamic Load Rating Cr (N) 125000
3. Basic static load rating, radial (C 0r) "237000.0000"
4. Limiting speed (n G) "4600.0000"
5. Reference speed (n ϑr) "2800.0000"
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NKI, light series

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
