NKI9/12-XL INA

All dimensions

1. Inner (d) MM 9
2. Outer (D) MM 19
3. Width (B) MM 12
4. Inner (d) Inch 0.3543
5. Outer (D) Inch 0.748
6. Width (B) Inch 0.4724
7. Width (b) mm 12

Suffix description

1. XL X-Life

Technical details

1. Availability 139 pcs
2. Brand INA
3. Item number NKI9/12-XL INA
4. Also known as 0507615360000
   NA091912
   NBI91912
   NKI9/12
   NKJ9/12
   TAFI91912

5. EAN 4012802212518
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.017

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 7100
2. Radial Dynamic Load Rating Cr (N) 7200
3. Limiting speed (n G) 26500
4. Reference speed (n ϑr) 20200
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NKI, light series
