NKI85/26-XL INA

All dimensions

1. Inner (d) MM 85,00
2. Outer (D) MM 115,00
3. Width (B) MM 26,00
4. Inner (d) Inch 3.3465
5. Outer (D) Inch 4.5276
6. Width (B) Inch 1.0236
7. Width (b) mm 26,00

Suffix description

1. XL X-Life

Technical details

1. Availability 69 pcs
2. Brand INA
3. Item number NKI85/26-XL INA
4. Also known as 0507628500000
   NA8511526
   NBI8511526
   NKI85/26
   NKJ85/26ASR1
   TAFI8511526

5. EAN 4012802268898
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.743

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 137000
2. Radial Dynamic Load Rating Cr (N) 83000
3. Basic static load rating, radial (C 0r) "137000.0000"
4. Limiting speed (n G) "4850.0000"
5. Reference speed (n ϑr) "3100.0000"
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NKI, light series
