NKI60/35-XL INA

All dimensions

1. Inner (d) MM 60
2. Outer (D) MM 82
3. Width (B) MM 35
4. Inner (d) Inch 2.3622
5. Outer (D) Inch 3.2283
6. Width (B) Inch 1.378
7. Width (b) mm 35

Suffix description

1. XL X-Life

Technical details

1. Availability 67 pcs
2. Brand INA
3. Item number NKI60/35-XL INA
4. Also known as 0507624940000
   NA608235
   NBI608235
   NKI60/35
   NKJ60/35A
   TAFI608235

5. EAN 4012802252453
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.553

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 139000
2. Radial Dynamic Load Rating Cr (N) 70000
3. Limiting speed (n G) 6800
4. Reference speed (n ϑr) 4050
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Needle roller bearings NKI, light series
